Description
HFP606025 is a composite gas box for low pressure gas distribution networks.
The gas box can be used to protect the regulator and gas meter from the elements. With a robust construction, developed and manufactured in Romania, the composite yarn has increased protection against mechanical actions.
Need help or more information? Contact a Homplex specialist now!
Informations
Functions
Available accessories
The HFP606025 gas box comes with a range of accessories always available – clips, screws, key and lock, service door, anchor or window panel and side wall.
Appearance preserved over time
Thanks to the material from which it is made (hot-pressed composites), the HFP606025 gas box does not corrode, does not require repainting or other treatments over time and retains its original appearance.
Increased resilience
The HFP606025 gas box benefits from a solid construction that facilitates high mechanical shock tolerance, excellent electrical insulating properties and thermal stability. Thanks to the added flame retardant and self-extinguishing additives, fire could be deterred and contained.
Increased safety!
The composite panel can be punched more easily and quickly, even using a cordless drill. The resulting perforation will be smooth, with no dangerous edges for those operating and handling the Homplex gas box.
Easy to handle
The unequipped Homplex gas box weighs approx. 4.4 kg and is much lighter than metal ones.
Quick check
Read the meter quickly without having to open the Homplex gas box thanks to the generous window.
Specifications
Material
Fibreglass reinforced anchoring panel, Hot molded polymer
Lock type
Standard triangle key
Brand
Homplex
Latch material
Polymer and steel
Gas box interior dimensions
605 x 215 x 605 mm
Gas box exterior dimensions
612 x 250 x 612 mm
Gas box window dimensions
180 x 76 mm
Unequipped gas box weight
4.4 kg
Color
RAL 7014 – mounting plate, ROL 7044 – Door and side panels
HFP 606025 version
Unequipped bas box
Associated Files
Frequent questions
Is it necessary to treat Homplex HFP606025 after a period of time?
Thanks to the composite polymers, the HPF606025 gas box does not need to be treated during its lifetime (this can even be ten years).
I lost the triangular key, how can I get a new one?
You can contact a Homplex specialist on 0374.49.49.49 to purchase a new key compatible with the HFP606025.
Why does the Homplex gas box have a triangular lock?
The key and hub of the HFP606025 are triangular in shape, as this type is frequently used in industry.
Unequipped composite gas meter box
Homplex HFP606025
Product code:
3713586
Unequipped composite Homplex gas meter box
- Available accessories
- Appearance preserved over time
- Increased resilience
- Increased safety!
- Easy to handle
- Quick check
