Description
FEX is a two-step gas pressure regulator. FEX can be mounted directly on the meter or on the gas pipe.
The purpose of the regulator is to keep the preset pressure constant (downstream – within the intended operating limits). This one keeps the pressure constant even when the inlet pressure and/or flow rate changes.
Informations
Functions
Specifications
Weight
2.7 kg
Nominal flow
75 m³ / h
Entry pressure
0.3 ... 8.6 bar
Exit pressure
100 ... 350 mbar (MP version) / 15 ... 500 mbar (BP version)
Automatic protection
UPSO / UPSO
Brand
Pietro Fiorentini
Connections
1" 1/4 x 1 1/4"
Nominal temperature
Room: - 20 °C ... + 60 °C
Under-pressure protection system
UPSO 6 ... 80 mbar (BP) / UPSO 80 ... 250 mbar (MP)
Overpressure protection system
OPSO 155 ... 500 mbar (MP) / OPSO 32 ... 160 mbar (BP)
AC
5 / 10%
Built-in relief valve (for network overpressure)
Yes
Standard filter
100 µm
Body material
Aluminium
Gas regulators
FEX
Product code:
3713692
Gas regulator for gas boxes
- Overpressure protection
- Underpressure - protection activated!
